| Model | D(mm) | H( mm) | L(mm) | Screw M | Magnetic Force( Kg) |
| TXA22 | 22 | 6 | 13.5 | 4 | 3 |
| TXA25 | 25 | 6 | 13.5 | 5 | 4 |
| TXA31 | 31 | 6 | 15 | 4、5、6 | 10 |
| TXA34 | 34 | 8 | 16.5 | 4 | 6 |
| TXA38 | 38 | 8.5 | 23.5 | 6 | 13 |
| TXA43 | 43 | 6 | 21 | 4、5、6 | 8.5 |
| TXA66 | 66 | 8.5 | 23.5 | 5、6、8 | 18 |
| TXA88 | 88 | 8.5 | 23.5 | 8、10 | 42 |
| | | |||
| Model | D( mm) | H( mm) | Screw M | Magnetic Force( Kg) |
| TXB22 | 22 | 6 | 4 | 3 |
| TXB25 | 25 | 6 | 5 | 4 |
| TXB31 | 31 | 6 | 4、5、6 | 10 |
| TXB34 | 34 | 8 | 4 | 6 |
| TXB38 | 38 | 8.5 | 6 | 13 |
| TXB43 | 43 | 6 | 4、5、6 | 8.5 |
| TXB66 | 66 | 8.5 | 5、6 | 18 |
| TXB88 | 88 | 8.5 | 6、8 | 42 |
| | | |||||
| Model | D( mm) | H(mm) | L( mm) | Screw M | d( mm) | Magnetic Force( Kg) |
| TXC22 | 22 | 6 | 13.5 | 4 | 6 | 3 |
| TXC25 | 25 | 6 | 13.5 | 5 | 8 | 4 |
| TXC31 | 31 | 6 | 15 | 4、5、6 | 8 | 10 |
| TXC34 | 34 | 8 | 14 | 4 | 8 | 6 |
| TXC38 | 38 | 8.5 | 15 | 6 | 8 | 13 |
| TXC43 | 43 | 6 | 10.5 | 4、5、6 | 8 | 8.5 |
| TXC66 | 66 | 8.5 | 15 | 5、6、8 | 10 | 18 |
| TXC88 | 88 | 8.5 | 19 | 5、8、10 | 12 | 42 |
